Arduino Smart Home Control Kit Price in Pakistan | AmpFlick

Description

Technical Specifications

The system utilizes an Arduino Uno as the central microcontroller for processing logic. Additionally, the Smart Home Control Kit features a 5V DC motor for ventilation. A micro servo motor handles precise 180-degree door movements. Two 220Ω resistors protect the LEDs from overcurrent damage. Therefore, the hardware ensures stable power distribution across all connected sensors and actuators.

Usage

Connect the servo to pin 9 and the DC motor via a transistor. Furthermore, link the light and fan LEDs to separate digital pins. This diagram shows all kit components connected to simulate working.

Advantages and Disadvantages

This Smart Home Control Kit offers a great introduction to embedded systems. However, the DC motor requires significant current during startup. Users benefit from hands-on coding experience with various mechanical parts. Additionally, the kit is highly modular for future sensor upgrades. Conversely, high-load appliances need extra relays not included here.

Precautions or What to Avoid

• Never connect the DC motor directly to Arduino pins without a driver.

• Avoid using a power supply exceeding 9V to prevent board overheating.

• Ensure all common ground connections are secure to prevent signal noise.

What’s Included in the Package

Microcontroller and Board

• 1 x Arduino Uno R3

• 1 x Solderless Breadboard

• 1 x SG90 Servo Motor

• 1 x 5V DC Motor

• 2 x 5mm LEDs

• 2 x 220 Ohm Resistors

• Bundle of M-M Jumper Wires



AND PLEASE NOTE THAT ALL COMPONENTS ARE UN-ASSEMBELED. You have to assemble the kit your self.



DRIVE LINK FOR .ino FILE AND CIRCUIT DIAGRAM: Click Here

Tutorial on how to assemble this this: Click Here

Order more Learning Kits from AmpFlick: Click Here
