ZK 5AD Dual H-Bridge Motor Driver

Description

ZK 5AD Motor Driver

The ZK 5AD is a dual H-bridge DC motor driver module designed for precise motor control. This ZK 5AD motor  features independent channel control for bidirectional motor operation. Specifically, engineers design it for robotics, automation systems, and industrial applications. The module offers high power output with small size and low power consumption. Additionally, it supports simple operation through conventional control methods. Visit our website Ampflick for more products and technical solutions.

How ZK 5AD Motor Driver Functions in Systems

This ZK 5AD motor driver operates by providing bidirectional control for DC motors. Moreover, it features dual H-bridge channels for independent motor operation. D0 and D1 control Motor 1, while D2 and D3 control Motor 2. The module supports high level signals from 2.2V to 6.0V and low level signals from 0.0V to 0.7V. In addition, D0 to D3 can receive control signals from MCU and other sources. Consequently, this ensures reliable motor performance across various applications. The module also supports 433MHz remote control for wireless operation. You can also visit our Instagram and Facebook for latest updates.

Technical Specifications of ZK 5AD Module

• Product Name – 5A Dual Motor Drive Module (ZK-5AD)

• Working Voltage – DC 3.0V to 14V

• Input Signal Voltage – DC 2.2V to 6.0V

• Drive Current – 5A per channel

• Stand-by Current – 10uA (low power consumption)

• Working Temperature – -20°C to 85°C

• Working Humidity – 0% to 95% RH

• Size – 38 x 27 x 18mm

• Mounting Hole Diameter – 2mm

• Dual Driver – Supports independent control for 2 motors

• Control Method – Conventional control with MCU interface

• Remote Support – 433MHz remote control compatible

Common Applications for ZK 5AD Driver

This ZK 5AD motor driver finds extensive application across multiple industries. For instance, engineers use it in robotic systems and mobile platforms. Industrial automation relies on this driver for conveyor and actuator control. Furthermore, DIY projects and educational kits benefit from its simple operation. The ZK 5AD is commonly utilized in electric vehicle prototypes and automation equipment. Similarly, medical devices and laboratory automation also use this motor controller.
