Infrared (IR) Flame Detection Sensor Module for Arduino

Description

Infrared (IR) Flame Sensor Module for Arduino

This flame or fire sensor module operates on the principle that burning flames emit infrared (IR) signals. The built-in IR receiver detects these signals, enabling flame or fire detection.

The sensor operates at 3V to 5.5V and provides both digital and analog outputs. The digital output sensitivity can be adjusted using the onboard potentiometer. It has a 60-degree detection angle with a theoretical range of 100 cm, though practical detection is 20-30 cm.

Brief Overview of IR Flame Sensor:

• Includes a photodiode for IR detection

• Features SMD resistors (10K-2No, 1K-2No)

• SMD capacitors (100nF-2No)

• 10K potentiometer for sensitivity adjustment

• Equipped with two SMD LEDs for status indication
