Dc 0 To 25v Voltage Sensor Module In Pakistan

Description

Dimensions: 28 x 14 x 13 mm(LxWxH).
Weight: 4 gm.
Input Voltage range: DC0 to 25 V
Voltage detection range: DC 0.02445 V to 25 V
Analog Voltage resolution : 0.00489 V
Output Interface : “+ ” connected 5/3.3V, “-” connected GND, “s” connected Arduino AD pins
DC input interface: red terminal positive with VCC, negative with GND
You can also use the IICLCD1602 LCD to display voltage.
By 3P connector, connect this module with the expansion of board Arduino, not only makes it easier for you to detect voltage battery
