Description

4WD Acrylic Chassis for RC Car: High-Traction Robotic Base

Technical Specifications of 4WD Acrylic Chassis for RC Car

• Main Material: Dual-layer high-grade 3mm transparent laser-cut acrylic plates.

• Dimensions: Approximately 255mm in length and 150mm in width for expanded builds.

• Drive System: Four-wheel drive powered by four independent high-torque geared motors.

• Motor Ratio: Standard 1:48 reduction ratio for balanced speed and torque.

• Wheel Parameters: Four 65mm diameter rubber tires with superior grip treads.

• Mounting Features: Multi-level pre-drilled holes for Arduino, Raspberry Pi, and sensors.

• Voltage Input: Motors operate efficiently between 3V and 6V DC.

• Load Capacity: This 4WD Acrylic Chassis for RC Car supports up to 1kg of hardware.

Assembly and Multi-Motor Integration

• First, remove the protective film from both of the acrylic chassis plates.

• Next, mount the four gear motors using the included heavy-duty T-brackets.

• Then, attach the rubber wheels to each motor shaft for a 4WD setup.

• Afterward, use the spacers to create a second deck for additional electronics.

• Furthermore, install your motor drivers and microcontrollers on the upper platform.

• Finally, connect the 4-slot battery box to provide power to all motors.

Advantages and Disadvantages of 4WD Acrylic Chassis for RC Car

• Pros: The four-wheel drive system provides excellent traction and off-road capability.

• Moreover, the dual-layer design offers double the mounting area for complex sensors.

• Cons: Managing four motors requires a higher current output from your battery source.

• Additionally, the assembly process is more time-consuming compared to 2WD basic kits.

Precautions and Structural Care

• Warning: Ensure all four motors are synchronized in code to prevent dragging.

• Avoid dropping the chassis on hard surfaces as the acrylic may shatter.

• Do not exceed 6V on the motors to maintain gear teeth integrity.

What is Included in the Package

• 1x Precision-cut 4WD Acrylic Chassis for RC Car base plates.

Only one transparent acrylic board will come with the package, no other accessories included
