High-Voltage 10uF 400V Electrolytic Capacitor for Power Supplies

Technical Specifications of 10uF 400V Electrolytic Capacitor

• Capacitance: Fixed 10uF value for high-voltage energy storage and filtering.

• Voltage Rating: High 400V DC rating designed for primary-side power applications.

• Dielectric Material: Premium aluminum electrolytic construction ensures long-term reliability.

• Terminal Type: Radial leads specifically designed for standard through-hole PCB mounting.

• Polarity: Clearly marked polarized terminals requiring correct orientation during installation.

• Tolerance: Standard ±20% capacitance variance suitable for power regulation stages.

• Form Factor: Compact cylindrical case optimized for space-constrained electronic housings.

• Application Range: This 10uF 400V Electrolytic Capacitor is essential for AC-DC converters.

Usage and High-Voltage Rectification

• First, identify the negative terminal marked by the white stripe on the body.

• Next, insert the leads into the high-voltage section of your rectified circuit.

• Then, utilize the capacitor to smooth high-voltage DC ripples in power adapters.

• Afterward, integrate it into LED drivers for flicker-free lighting performance.

• Consequently, the 10uF 400V Electrolytic Capacitor maintains stable output during load transitions.

• Finally, solder the leads securely to prevent arcing in high-tension environments.

Advantages and Disadvantages of 10uF 400V Electrolytic Capacitor

• Pros: Offers a massive 400V breakdown voltage within a relatively small physical footprint.

• Furthermore, it provides excellent ripple current handling for switch-mode power supply (SMPS) designs.

• Cons: Electrolytic capacitors have a finite lifespan and may dry out under extreme heat.

• Additionally, reverse polarity connection will cause immediate failure or physical rupture.

Precautions and Safety Guidelines

• Warning: Discharge the capacitor fully before handling to avoid lethal electrical shocks.

• Never exceed the 400V limit to prevent internal dielectric breakdown and gas buildup.

• Avoid placing the component near high-heat sources like power transistors or transformers.

What is Included in the Package

• 1x 10uF 400V Capacitor (Aluminum Radial Through-Hole).

• Protective industrial packaging to maintain lead straightness during shipping and handling.
